Edge Trim-ES28-280-P80 - Elasto Proxy

ES28-280-P80

Request for a Quote & Information

Product Overview & Description

VM2-FF1530-R50_REV0 by Elasto Proxy on Sketchfab

VM2-MF1530-R50 is a cylinder-shaped vibration mount that consists of natural rubber bonded to zinc-plated steel. This anti-vibration mount has a threaded-hole for an M5x0.8 metric fastener. If the fastener is screwed-in so that the head is flush with the top of the cylinder, the fastener extends 15.0 mm ± 1 mm from the bottom of the cylinder. This main body of this vibration control product is 30.0mm tall.

Technical Drawing & Specification

MATERIAL: Natural Rubber/Steel
WIDTH: As shown
HEIGHT: As shown
TOLERANCE: RMA-A2
SCALE: Not to scale
COLOR: Black
DURO: 50 ±5

Bending Radius & Additional Information

VM2-MF1530-R50 is an anti-vibration mount with a cylindrical body and a threaded fastener for attachment. The main body consists of natural rubber bonded to zinc-plated steel. Natural rubber resists abrasion and tearing. Zinc-plated steels offers corrosion resistance. The fastener for the threaded through-hole is an M5x0.8 metric screw. Applications include industrial machinery and equipment.
