Window Channel-ES38-002-E80

ES38-002-E80

Request for a Quote & Information

Product Overview & Description

ES38-002-E80 REV2 by Elasto Proxy on Sketchfab

ES38-002-E80 is an 80-durometer window channel made of solid EPDM rubber. This window seal has a larger rounded section and three smaller rounded sections. Two of these smaller sections have scalloped features. The third section has gradual slopes. ES38-002-E80 is 10.4 mm tall and measures 8.1 mm at its widest.

Technical Drawing & Specification

MATERIAL: EPDM
WIDTH: As shown
HEIGHT: As shown
TOLERANCE: RMA-E2
SCALE: Not to scale
COLOR: Black
DURO: 80 ±5

Bending Radius & Additional Information

ES38-002-E80 is a window channel that is made of solid EPDM rubber. It is 8.1 mm at its widest point and 10.4 mm tall. The top and bottom of this window seal have identically-shaped rounded features. There is also a third and differently shaped rounded feature on the left-side of the seal. The right-side is contoured.
